Technical Specifications
| Feature |
Details |
| Part Type |
Front headlight / headlamp assembly with projector-type Bi-HID housing design and upper LED signature light |
| Grade / Quality |
Aftermarket replacement part |
| Compatibility |
Chevrolet Equinox LT and RS 2021–2023 with the facelift front end and matching lamp housing, electrical connector, modules and mounting configuration |
| Model Years |
2021–2023 |
| Installation Position |
Front exterior lighting area beside the grille and above the front bumper |
| Side |
Right passenger side, left driver side, or pair according to the selected option and product images |
| Construction Material |
Clear lens with black molded lamp housing |
| Lighting Configuration |
Bi-HID-style projector housing with upper LED signature / daytime-running-light element; bulbs, ballast and control modules must match the original configuration |
| OEM Reference Numbers |
Left/Driver: 86517974; Right/Passenger: 86517975 |
| Superseded References |
No superseded reference entered from the official GM product pages |
| Part Function |
Provides the forward low- and high-beam headlamp functions and the pictured upper signature-light function when connected to a compatible vehicle system |
| Package Includes |
One headlight for the selected side, or one right and one left headlight when the pair is selected; bulbs, ballast, LED driver/control modules, brackets, wiring adapters and mounting hardware are included only when shown and stated |
| Fitment & Installation |
Install at the original headlamp mounting points, connect the compatible electrical plug and required modules, verify every lighting function, then aim the headlamp to the vehicle specification; professional installation is recommended |
Technical Note:
The pictured assemblies match the shape and lighting layout of GM references 86517974 (left/driver) and 86517975 (right/passenger), which GM lists for Equinox LT and RS 2022–2024. The listed numbers are OEM references used for fitment identification only and do not indicate that this aftermarket product is genuine. Compare the original part number, housing and lens shape, connector and pin layout, Bi-HID/LED equipment, ballast and modules, mounting points and VIN before ordering. Headlamp aiming is required after installation. Fitment can vary within the listed model-year range; compare the vehicle body shape, original part, product images and mounting points before ordering.
